Industrial Packaging

Chipboard Sheets

The thickness/caliper of our chipboard ranges from .006 to .06 (6 to 60mil) and we offer sheet sizes up to 72"W to 360"L. CSM Paper and Film also offers Die Cut capabilities for custom sheets and trays as well as headers, coil caps, and circles.

We can also offer a wide array of lamination benefits:

Chip to chip for increased strength
Clay lamination for improving suction for suction cups in high speed applications.
Our poly application is oil resistant and water proof.
Our foil application works perfectly as a heat barrier.

Standard Basis Weights: Various
Sheet Sizes: 72 Max Width, 360’’ Max Length
Capabilites:

Die Cut
Lamination
Poly Coated

Primary uses include shirtboard, interleaver, dust covers, separator sheet, pallet cover and backing sheet on writing
paper.

Cores and Tubes

What We Offer:

Film Cores
Shipping Tubes
Composite Cans
Construction Cans
Custom Printed Cores/Tubes
Food Grade Tubes
Mailing Tubes - Kraft and White
Prestretch Cores
Turf Tubes

Capabilities:

Inside Diameters: .51" to 30"
Lengths: 1/4" to 250"
Wall Thicknesses: .030" to .750"
Inner/Outer Plys: Brown Kraft, Colors, Printed, Silicone, Wax, White, White Litho
Cuts: Blade and Saw
Closures: Plastic or Metal Plugs

Kraft Paper - Sheets & Rolls

RECYCLED KRAFT

Standard Basis Weights: 30#, 40#, 50#, 60#, 70# and 90#

Roll or Sheets: Custom and Standard Sizes available

This product is a recycled sheet, however, it continues to have a high tear resistance as well as bursting strength. This product is preferred by users as void fill due to the soft feel of the sheet.

VIRGIN KRAFT

Standard Basis Weights: 30#, 40#, 50#, 60#, 70# and 90#

Roll or Sheets: Custom and Standard Sizes available

This product has very high tear/burst strength. Our Virgin Kraft is made up of 80% virgin and 20% recycled material. When comparing virgin to recycled, you will find virgin to be a cleaner sheet with a smoother finish. Virgin tends to be used when a crisp, clean sheet is needed. The primary application for Virgin Kraft is to wrap products for protection.

Singleface - A and B Flute - Sheets & Rolls

Singleface corrugated is a product used for multi purposes. It typically is produced on a roll, but can be die cut or produced in sheet form. Singleface is produced with a ply of linerboard adhered to a fluted medium ply. As opposed to corrugated, this product is flexible and can be used to wrap products needing protection. The flute size determines grade: A flute is the largest, B flute has a smaller more compact flute and is more cost-effective.

Cornerboard

Cornerboard—also known as edge protector or angleboard—is a simple yet essential packaging solution. It’s typically made from compressed recycled paperboard and formed into a 90-degree angle. This shape allows it to:

Protect edges and corners of products from dents, abrasions, and compression
Stabilize loads during transit, especially when shrink wrap or strapping is applied
Improve stacking strength for palletized products

Air Bags

Woven Poly Airbags

LEVEL I
Transportation Mode/products:

Truck/Container
Glass bottles
Paper Products
Furniture
Beer/Wine
Dry Good Products
Paper Equivalent: 2 ply paper bags
Max Air pressure: 2-3 PSI

Level II
Transportation Mode:

Truck (piggyback-container or trailer on the Railroad)
Container
Ocean
Paper Equivalent - 4 ply paper air bags
Max Air Pressure: 6 PSI

LEVEL III - IV
Bags Transportation/product Mode:

Most Railroad applications use the Level III-IV. For rail cars with load weights from 75,000 to 205,000 lbs
Ocean Transport
Paper Mill Rolls Plywood
Bricks
Paper Equivalent: 8 ply paper air bags
Max Air Pressure: 8 PSI

LEVEL V
Bags Transportation Mode:

Railroad use for heavy applications. For rail cars with load weights exceeding 205,000 lbs
Ocean - Vertical or horizontal position in void
Paper Equivalent: Level V bags have no paper equivalent as paper bags are NOT capable of meeting the strength requirements of the AAR.
Max Air Pressure: 10 PSI

Bison Bag Bags Transportation Mode:

Truck
Light duty cargo
NOT AAR approved
Paper Equivalent: 2 ply paper air bags
Max Air Pressure of 2-3 PSI

Roll Edge Guard

Roll Edge Guard is a lightweight, easy-to-apply protective strip engineered to safeguard the vulnerable edges of cylindrical products. Whether you're shipping paper rolls, metal coils, wire spools, or cabling, Roll Edge Guard helps prevent tearing, crimping, and edge deformation.

Linerboard/Medium

Standard Basis Weights: 26#, 33#, 35#, 42#, 69# and 99#

Roll or Sheets: Custom and Standard Sizes available

Unbleached kraft Linerboard is a grade of paperboard used in the production of corrugated containers or boxes. The inner and outer facing (liner) is used in combination with the corrugating medium (the fluted inner sheet) to form the rigid structure of the combined board. Most unbleached kraft linerboard is made from the kraft process of softwood chips that have long fibers, which make the strongest board.

This product can be used for a variety of applications including lining railcars, floor protection, pallet covers and on construction sites.

Raw material grades:

Virgin Kraft
Lightweight Linerboard

Newsprint - Sheets & Rolls

Standard Basis Weights: 30#

Roll or Sheets: Custom and Standard Sizes available

Newsprint is a low-cost, clean and environmentally friendly product. This product can also be cut into pre-cut sheets.

Primary markets:

Moving and storage industry;
Parts and glass industry;
Dunnage material;

Anti-Slip Sheets

Bogus Paper

Bogus paper is a low-cost, high-bulk packaging paper made from a mix of recycled materials such as:

Old newsprint (ONP)
Old corrugated containers (OCC)
Chipboard and other post-consumer waste
This blend gives it a gray or brown color and a soft, fluffy texture, making it distinct from denser papers like Kraft.

Poly Coated Papers
